| Max operation speed |
AL-Plastic-AL : up to 30 cycles/min |
| AL-AL : up to 35 cycles/min |
| AL-PVC : up to 50 cycles/min |
| Format range |
Effective Index width: Max. 110X240mm |
| Depth Max. :12mm |
| Width of Forming film: Max.250mm |
| Width of Lidding Material: Max.250mm |
| Tropical blister foil : Max.250mm |
| Packaging materials |
Forming Material : PVC,PVC/PVDC,PVC/ACLAR,PP,PET,Alu forming material, etc. |
| Lidding Material:PTP,PP etc Heat-sealable lacquered material |
| Machine size |
5,100X650X1,700mm(LXWXH) |
| Weight |
2,100kg |
| Electric power connection |
380V 50Hz 5.5Kw(Three-Phase Four-Wires) |
| Compressed Air Pressure |
0.5-0.7MPa |
| Air Consumption |
150NL/min |
